Flange Facers, OD Mount
With various models of OD mount flange facers to reface, mill, bevel, square, counterbore, or cut end prep configurations for welding, CLIMAX offers a wide variety of rugged and innovative portable flange facers, for 0 to 120 inch (0 to 3050 mm) diameters, for OD mounting, and several of our machines can be configured for facing, milling, or both! For easy setup, larger units can be installed with a separate mount or chuck to which the facer body is installed.
With 29 models to choose from, CLIMAX flange facers can tackle an unrivaled range of applications from 0 to 199 inches (0 to 5054 mm) – VIEW BROCHURE.
| SPECIFICATIONS | INCH | METRIC | |||
| Facing Diameter | 0 – 12 in. | 0 – 304.8 mm | |||
| Feed Rate | 0 – 0.035 in./rev | 0 – 0.889 mm/rev | |||
| OD Mounting Diameter | 2 – 12 in. | 50.8 – 304.8 mm | |||
| Power Option | Pneumatic | Pneumatic |
| SPECIFICATIONS | INCH | METRIC | |||
| Facing Diameter | 0 – 12.5 in. | 0 – 317.5 mm | |||
| Feed Rate | 0 – 0.035 in./rev | 0 – 0.889 mm/rev | |||
| OD Mounting Diameter | 2 – 14.1 in. | 50.8 – 358.1 mm | |||
| Power Option | Pneumatic | Pneumatic |
| SPECIFICATIONS | INCH | METRIC | |||
| Facing Diameter | 0 – 24.5 in. | 0 – 622.3 mm | |||
| Feed Rate | 0 – 0.035 in./rev | 0 – 0.889 mm/rev | |||
| OD Mounting Diameter | 8 – 26 in. | 203.2 – 660.4 mm | |||
| Power Option | Pneumatic | Pneumatic |
| SPECIFICATIONS | INCH | METRIC | |||
| Facing Diameter | 0 – 36.5 in. | 0 – 927.1 mm | |||
| Feed Rate | 0 – 0.035 in./rev | 0 – 0.889 mm/rev | |||
| OD Mounting Diameter | 20 – 38 in. | 508 – 965.2 mm | |||
| Power Option | Pneumatic | Pneumatic |
| SPECIFICATIONS | INCH | METRIC | |||
| Facing Diameter | 8.5 – 60 in. | 215.9 – 1524.0 mm | |||
| Milling Diameter | N/A | N/A | |||
| ID Mounting Diameter | 11.8 – 57.5 inches | 299.7 – 1460.5 mm | |||
| OD Facing Diameter | 8.5 – 60 inches | 215.9 – 1524.0 mm | |||
| OD Mounting Diameter | 38.1 – 63.8 in. | 967.7 – 1620.5 mm | |||
| Power Option | Pneumatic or Hydraulic | Pneumatic or Hydraulic |
| SPECIFICATIONS | INCH | METRIC | |||
| Facing Diameter | 0 – 120.5 in. | 0 – 3061 mm | |||
| Milling Diameter | N/A | N/A | |||
| OD Mounting Range | 9.2 – 120.5 in. | 234 – 3061 mm | |||
| Power Option | Pneumatic | Pneumatic |
| SPECIFICATIONS | INCH | METRIC | |||
| Facing Diameter | 45 – 120 in. | 1143 – 3048 mm | |||
| Milling Diameter | 45 – 120 in. | 1143 – 3048 mm | |||
| ID Mounting Diameter | 45 – 120 inches | 1143 – 3048 mm | |||
| OD Mounting Diameter | 89.8 – 136.4 in. | 2280.9 – 3464.6 mm | |||
| Power Option | Pneumatic or Hydraulic | Pneumatic or Hydraulic |
| SPECIFICATIONS | INCH | METRIC | |||
| OD Single-Point Diameter | 69.5 - 199.0 in. | 1765.3 - 5054.6 mm | |||
| OD Milling Diameter | 69.5 - 184 in. | 1765.3 - 4673.6 mm | |||
| OD Mounting Diameter | 98.4 - 209.9 in. | 2499.36 - 5331.46 mm | |||
| Power Options | Electric Servo | Electric Servo |
